DoorBird A1103 WiFi IP Video Indoor Station

WiFi Indoor Video Monitor for DoorBird Entry Systems

The DoorBird A1103 WiFi IP Video Indoor Station is an indoor video monitor for DoorBird IP video door communication systems used in residential, commercial, and public building applications. It connects by 2.4 GHz WiFi or LAN/PoE and gives users an indoor screen for viewing visitors, speaking with them, and controlling connected doors, gates, or elevator functions.

When paired with a compatible DoorBird IP Video Door Station, the A1103 provides live video, two-way audio, visitor history, room-to-room communication when multiple indoor stations are used, and SIP support for concierge or facility manager calls. The 7-inch True IPS capacitive touch display provides a clear indoor interface for DoorBird systems without relying only on a mobile app.

For access control and perimeter entry applications, the A1103 helps occupants manage visitors from inside the building. Its two bistable latching relays can be used for an electric door opener, gate release interface, or elevator call function when wired according to the DoorBird system design. The connected lock, opener, or release device requires its own separate power supply.

The A1103 is designed for indoor installation and is available in white and black variants. It supports surface mounting, optional table stand placement, DoorBird App configuration, web-based dashboard configuration, and integration with smart building functions through IP, TCP, HTTPS, relays, and compatible DoorBird system features.

Key Features

• DoorBird A1103 WiFi IP Video Indoor Station
• Available in white and black variants
• Connects by 2.4 GHz WiFi or LAN/PoE
• Designed for DoorBird IP video door communication systems
• For residential, commercial, and public building applications
• 7-inch True IPS capacitive touch display
• 1024 x 600 display resolution
• Two-way audio with speaker and microphone
• Echo and noise cancellation
• Door opener and gate release control through connected DoorBird system
• Elevator control support through relay function
• Room-to-room communication when multiple indoor stations are used
• SIP support for concierge or facility manager calls
• Visitor history with free Cloud Recording
• Configurable tile view
• Configurable RGB LED status bar for visitors and missed calls
• DoorBird App and web-based dashboard configuration
• Two digital inputs, commonly used for storey-call buttons
• Two bistable latching relays for door opener, gate release, or elevator functions
• Surface-mounted design
• Table stand sold separately
• Designed, developed, and made in Germany

Technical Specifications

• Manufacturer: DoorBird / ASSA ABLOY
• Model: A1103
• Product Type: WiFi IP video indoor station
• Available Variants: White and black
• Application: Indoor monitor for DoorBird IP video door stations
• Supported Door Stations: Any DoorBird IP Video Door Station
• Display: 7-inch True Color LCD
• Touchscreen: Capacitive touch
• Resolution: 1024 x 600 px
• IPS Display: Yes
• Audio: Speaker and microphone
• Audio Processing: Echo and noise cancellation, AEC and ANR
• Audio Streaming: Two-way
• Network Connection: 2.4 GHz WiFi or RJ45 LAN/PoE
• WiFi: 802.11 b/g/n 2.4 GHz
• Ethernet: 10/100 Base-T
• PoE Standard: PoE IEEE 802.3af Mode A
• Power Supply: 15 to 48 VDC, minimum 15 W, or PoE
• Power Consumption: Max. 10 W
• Digital Inputs: 2, dry input, 0 V / 0 A normally open
• Relay Outputs: 2 bistable latching relays
• Relay Rating: Max. 24 VAC/DC, 1 A
• Relay Use: Electric door opener, gate release interface, or elevator control
• Connected Device Power: Door opener, gate release, or elevator device requires separate power
• Material: Polycarbonate and glass
• Mounting Type: Surface-mounted
• Optional Mounting: Table stand sold separately
• Installation Box Compatibility: European standard 68 mm hollow-wall box or US single-gang box
• Dimensions: 146 mm H x 185 mm W x 26.04 mm D
• Weight: 510 g
• Operating Conditions: 32°F to 131°F, 0°C to 55°C
• Humidity: 0% to 85%, non-condensing
• Indoor / Outdoor Use: Indoor use only
• Included Components: IP Video Indoor Station, mounting bracket, power supply unit with country-specific adapters, Quickstart guide with Digital Passport, installation manual, and small parts
• Approvals: CE RED, IEC/EN 62368, FCC, IC, REACH 250, RoHS 2.0, California 65, WEEE
• System Requirements: Current iOS or Android mobile device, high-speed broadband Internet, and Ethernet network with DHCP
• Installation Note: Do not power the device by PoE and DC power supply at the same time
• Warranty: Manufacturer warranty, see DoorBird warranty terms

Conclusion

The DoorBird A1103 WiFi IP Video Indoor Station adds an indoor video and audio control point to compatible DoorBird door and gate entry systems. It supports WiFi or LAN/PoE connection, live visitor viewing, two-way communication, door or gate release control, room-to-room communication, SIP calling, and smart building functions through the DoorBird platform. This listing can be offered with white and black variants for projects that need the same A1103 indoor station in different finishes.

Special order item. Not returnable.
